Large A-Frame House
Large Model
2 Floors
3-4
3 - 5
110 - 190
8.0 m
Experience the pinnacle of luxury and comfort with our expansive two-floor Large Homes, ranging from 110 to 190 sqm. These grand residences boast 3 or 4 bedrooms and 3 to 5 bathrooms, offering ample space for your family and guests. From elegant dinner parties in spacious living areas to serene moments in sumptuous master suites, every detail is crafted to elevate your lifestyle. Embrace the beauty of panoramic views and custom touches, creating a haven where cherished memories are made and dreams come true.
Interior
KITs include:
Documents
- 1. Paper work
- 2. Architectural plan
- 3. General furniture plan
- 4. Tiling plan
- 5. Ceiling plans with levels
- 6. Elevations
- 7. Construction manual
Carrier System
- External Wall: 40*60*1.5mm Anti-rust Welded Frame
- Internal Wall: 40*60*1.5mm Anti-rust Welded
- Frame Roof: 50*100*2.5mm Special Truss System Welded
- Floor: 50*100*2.5mm Chassis System Welded
Facade Cladding System and Insulation
- Exterior: 40mm Sinus Panel - Polyurethane Density
- 40 (±2) kg/m3 (Anthracite Gray) Boardex facade cladding
- + Mesh + Exterior plaster + Minerally Plaster + Paint Local
- Thermowood Natural Wood Paneling Application
- Exterior Facade Insulation: 40 mm Polyurethane Density 40 (±2) kg/m
- 3 +30 mm Spray Polyurethane Foam + 40mm Mineral Wool
- Non-flammable Class 1A Thermal Conductivity 0.040 W/mK
- Interior: Gypsum Board, Gypsum Plaster, Plaster Primer and Silicone
- Interior Facade Paint + Local Wood Paneling Application.
- Interior Wall Insulation: 50mm Mineral Wool
- Fireproof Class 1A Thermal Conductivity 0.040 W/mK
Roof Covering System and Insulation
- Roof Covering: 3-Rib Sandwich Roof Panel
- Polyurethane Density 40 (±2) kg/m3
- Roof Insulation: 40mm Polyurethane
- Density 40 (±2) ) kg/m3
- Roof Additional Insulation: 30 mm Spray Polyurethane Foam
- + 100mm Glass Wool - Density 40 (±2) kg/m3
Doors and Windows
- Exterior Door: Water-Resistant Exterior Aluminum Steel Door Interior
- Doors: Melamine Surface Panel Door.
- Windows: Anthracite Gray Self-Sill PVC Window.
- Windows: 4+16+4 double glazing.
Optional Features
- Household Appliances
- Home Furniture
- Solar Panels
- Interior Circulation Design
- Floor Heating
- Attached Pergola
- Smart Home
- Landscape Design
- Swimming Pool
- Interior And Exterior
